Travel speed can arrive 6000mm/min and very stable.
Effective cutting rang 2500mm by 3400mm, much bigger than the competitors in same industry even can
compete with gantry type cutting machine!
Standard configuration Arc voltage (or Capacitance) auto torch height control
Use the structure mixing servo motor drive and reducer
Standard working size 2500mm x 3400mm
Cutting thickness: 2–32mm by plasma
Hybrid servo motor 0–6000mm/min
| Model | HNP-2500×3400 |
| Input voltage | 110V/220V/380V/440V/600V |
| Power supply frequency | 50/60Hz |
| Rate power | 300W |
| Transverse effective cutting | 2500mm |
| Longitudinal effective cutting | 3400mm length, can be extended to 20 meters |
| Cutting speed | 0–6000mm/min |
| Cutting thickness (flame) | 6–80mm mild steel |
| Cutting thickness (plasma) | 2–32mm Depends on plasma power capacity |
| Machine weight | 150KG |
| Pressure of plasma cutting gas | ≤1MPa |
| Packing size of the rail and beam | 4100×450×200mm |
| Package size of host machine | 660×550×435mm |
| Electric torch lifting | standard configuration |
| Torch height control | standard configuration |
| Solenoid valve control | standard configuration |
| Driving mode | Hybrid servo motor (with encoder feedback) |
